In this problem set, you will be implementing a simplified version of Google's MapReduce. Prior to starting this problem set, you should read the short paper on MapReduce to familiarize yourself with the basic MapReduce architecture. This writeup will assume that you have read sections 1–3.1 of that paper.
The map and reduce functions have the following OCaml types:
val map : 'a -> 'b -> ('c * 'd) list val reduce : 'c -> 'd list -> 'e list
These functions will be computed in a distributed fashion by several agents running concurrently. The agents communicate with each other using a messaging protocol defined in shared/protocol.ml. However, that protocol only allows for the transmission of strings, so you must use OCaml's built-in marshalling and unmarshalling facilities to transmit values of different types. We will explain this more thoroughly below.
For a given MapReduce application foo
, the application-specific code
is stored in the directory apps/foo/. The code for the mappers is in
apps/foo/mapper.ml and the code for the reducers is in
apps/foo/reducer.ml. There is also a controller in the file
apps/foo/foo.ml to handle the initialization of and communication with
the mappers and reducers, reading inputs, and printing results.
The mappers and reducers receive
their input by calling Program.get_input
and communicate their
results by calling Program.set_output
. The specific mechanisms
for these operations are described below.
Execution is divided into five phases:
controller.exe
is invoked with the name of a MapReduce application on the command
line along with other application-specific information (e.g., input file name,
any other parameters as required by the application). This information is passed to
main
method of the controller in the application directory.
This method reads the data from the input file
and parses it into a list of (key, value) pairs to provide as input to the mappers.
It then connects to worker servers and initializes mappers on these servers.
The controller sends each (key, value) pair to an available mapper. The mapper calculates the mapping function on this (key, value) pair, resulting in a list of (key, value) pairs (the types of the input and output do not have to be the same). The resulting list of (key, value) pairs is sent back to the controller. The controller continues to send inputs to the next available mapper until all pairs have been mapped.
For each key produced by the mappers, all of its corresponding values are collected into a single list, resulting in a (key, value list) pair for that key.
The controller connects to worker servers and initializes reducers on these servers. The (key, value list) pairs produced in the Combine phase are then sent to available reducers. The reducers perform the reduce operation and send the results back to the controller. This continues until all input has been reduced.
The controller collects the results of the Reduce phase and outputs them in some manner.
Consider the canonical MapReduce example of counting the number of occurrences of each word in a set of documents. The input is a set of (document id, contents) pairs. In the Map phase, each word that occurs in the contents of a file is mapped to the pair (word, "1"), indicating that the word has been seen once. In the Combine phase, all pairs with the same first component are collected to form the pair (word, ["1"; "1"; ...; "1"]), one such pair for each word. Then in the Reduce phase, for each word, the list of ones is summed to determine the number of occurrences of that word.
For simplicity, our framework accepts only a single data file containing all the
input documents. Each document is represented in the input file as a
(id, document name, contents) triple. See
data/reuters.txt or the shorter files data/test1.txt
or data/test2.txt for an example of the formatting.
Document files can be loaded and parsed by calling
Util.load_documents
. The dataset
data/reuters.txt is a collection of Reuters articles from the 1980's.
We have included a full implementation of this application in apps/word_count. Here is a detailed explanation of the sequence of events.
controller.exe word_count filename
. It immediately calls
the main
method of apps/word_count/word_count.ml
,
passing it the argument list. The main
method calls
controller/Map_reduce.map_reduce
, which is common controller code
for performing a simple one-phase MapReduce on documents. Other more involved
applications have their own controller code.
filename
are read in and parsed
using Util.load_documents
,
which splits the collection of documents into {id; title; contents} triples.
Map_reduce.map kv_pairs "" "apps/word_count/mapper.ml"
.
The second argument represents shared data that is accessible to
all mappers in addition to their input (key, value) pair. For this application,
there is no shared data, so this argument is the empty string. In general,
the shared data can be accessed by a mapper using Program.get_shared_data()
.
Map_reduce.map
initializes a mapper worker manager using
Worker_manager.initialize_mappers "apps/word_count/mapper.ml" ""
.
The Worker_manager
loads in the list of available workers from
the file named addresses. Each line of this file contains a
worker address of the form ip_address:port_number. Each of these
workers is sent the mapper code. The worker creates a mapper with that code and
and sends back the id of the resulting mapper. This id is combined with the address
of the worker to uniquely identify that mapper. If certain workers are unavailable,
this function will report this fact, but will continue to run successfully.
Map_reduce.map
then sends individual unmapped (id, contents)
pairs to available mappers until it has received results for all pairs. Free
mappers are obtained using Worker_manager.pop_worker()
. Mappers
should be released once their results have been received using
Worker_manager.push_worker
. Read
controller/worker_manager.mli for more complete documentation.
Once all (id, contents) pairs have been mapped, the new list of (word, "1")
pairs is returned.
Map_reduce.map_reduce
receives the results of the mapping.
If desired, Util.print_map_results
can be called here to display the
results of the Map phase for debugging purposes.
Map_reduce.combine
. The results
can be displayed using Util.print_combine_results
.
Map_reduce.reduce
is then called with the results of
Map_reduce.combine
, along with the (empty) shared data string
and the name of the reducer file apps/word_count/reducer.ml
.
Map_reduce.reduce
initializes the reducer worker manager by calling the
appropriate Worker_manager
function, which retrieves worker
addresses in the same manner as for mappers.
Map_reduce.reduce
then sends the unreduced (word, count list)
pairs to available reducers until it has received results for all input.
This is performed in essentially the same manner as the map phase. When
all pairs have been reduced, the new list of (word, count) tuples is
returned. In this application, because the key value doesn't change,
Worker_manager.reduce
and the reduce workers only
calculate and return the new value (in this case, count), but don't return
the key (in this case, word).
main
method of word_count.ml
,
which displays them using Util.print_reduce_results
.
Worker_server
receives a connection and spawns a thread, which
calls Worker.handle_request
to handle it.
Worker.handle_request
determines the request type. If it is an
initialization request, then the new mapper or reducer is built using
Program.build
, which returns either the new worker id or
the compilation error. See worker_server/program.ml for more complete
documentation. If it is a map or reduce request,
the worker id is verified as referencing a valid mapper or reducer, respectively.
If the id is valid, then Program.run
is called with that id and
the provided input. This runs the relevant worker, which receives its input
by calling Program.get_input()
. Once the worker terminates, having
set its output using Program.set_output
, these results are returned
by Program.run
. If the request is invalid, then the appropriate
error message, as defined in shared/protocol.ml, is prepared.
Worker.send_response
is called, which is responsible for
sending the result back to the client. If the response is sent successfully,
then Worker.handle_request
simply recurses, otherwise it returns unit.
controller/
controller/main.ml
This is the main module that is called to start up an application. It does not do anything except parse the command-line arguments to determine which application to start, then calls the main method of that application, passing it the command-line arguments.
map_reduce.ml
This module provides functionality for performing the actual map, combine, and reduce operations. These methods can be called by the individual applications. A more thorough description is given below.
The method map_reduce
in this module contains controller code
common to a number of applications that manipulate documents. It can be used with different
mappers and reducers to achieve different results. It loads and parses the documents
from the input file, then calls Map_reduce.map
to run the mappers.
Next, the list of (key, value)
pairs are combined using Map_reduce.combine
. The combined values are then reduced
using Map_reduce.reduce
. These results are passed back to the individual
application controllers for output.
worker_manager.ml
This module provides the capability to initialize mappers and reducers,
select inactive workers using the pop
function, assign a
map/reduce task to a worker using either the map
or
reduce
function, and return workers that have completed
their task to the pool of inactive workers using the push
function.
If a request fails due to some sort of network or file descriptor error,
then the Worker_manager
will automatically retry a fixed number
of times. It is therefore acceptable for workers to intermittently output
errors as long as they are still able to service requests.
worker_server/
program.ml
This module provides the ability to build and run mappers/reducers.
worker_server.ml
This module is responsible for spawning threads to handle client connection
requests. These threads simply invoke Worker.handle_request
.
worker.ml
This module is responsible for managing communication between the clients and the mappers/reducers that they build and then run. A more thorough description is contained below.
The protocol that the controller application and the workers use to communicate is stored in shared/protocol.ml.
InitMapper (code, shared_data)
Initialize a mapper. Each element in the code
list is a line in
mapper.ml. shared_data
is accessible to all mappers, as
described above.
InitReducer (code)
Initialize a reducer. Same as above.
MapRequest (worker_id, key, value)
Execute mapper with id worker_id
with (key, value)
as input.
ReduceRequest (worker_id, key, value list)
Execute reducer with id worker_id
with
(key, value list)
as input.
Mapper (worker_id option, error)
Mapper (Some id, _)
indicates the requested mapper was successfully
built, and has the returned id. Mapper (None, error)
indicates
compilation of the mapper failed with the returned error.
Reducer (worker_id option, error)
Same as above, except for a reducer.
InvalidWorker (worker_id)
Either a map request was made, and the worker_id
doesn't correspond to a
mapper, or a reduce request was made, and the worker_id
doesn't correspond
to a reducer.
RuntimeError (worker_id, error)
Worker with id worker_id
output the runtime error(s) stored in
error
. Also used to indicate that the worker didn't return any
output, meaning Program.run
returned None
.
MapResults (worker_id, (key, value) list)
Map request sent to worker_id
resulted in output of (key,
value) list
.
ReduceResults (worker_id, value list)
Reduce request sent to worker_id
resulted in output of
value list
.
Only string data can be communicated between agents.
Values can be converted to and from strings explicitly
using Util.marshal
, which calls the OCaml built-in Marshal.to_string
, and
Util.unmarshal
, which calls Marshal.from_string
.
You can send strings via communication channels without marshalling, but other
values need to be marshalled. Your mapper or reducer must also convert
the input it receives from strings back to the appropriate type it can operate on, and once
it has finished, it needs to convert its output into strings to communicate it back.
Note that marshalling is not type safe. If you unmarshal a string and treat it as a value of any type other than the type it was marshalled as, your program will most likely crash. You should therefore take particular care that the types match when marshalling/unmarshalling. Make sure that the type of marshalled input sent to your mapper matches the type that the mapper expects, and that the type of the marshalled results that the mapper sends back matches the type expected. The same is true for reducers using the reducer messages. You can still retrieve the type information by matching on the retrieved value.
All code you submit must adhere to the specifications defined in the respective .mli
files.
You must implement functions in the following files:
shared/hashtable.ml
You are required to implement a hash table according to the specifications
in shared/hashtable.mli. This data structure will be useful in your
MapReduce implementation. Note: You may not use the OCaml Hashtbl library functions in your implementation. The only exception is that you may use Hashtbl.hash
as your hashing function.
controller/map_reduce.ml
The code in this module is responsible for performing the actual map, combine, and reduce operations by initializing the mappers/reducers, sending them input that hasn't been mapped/reduced yet, and then returning the final list of results.
The map
and reduce
functions must be implemented
according to the specifications in controller/map_reduce.mli. The
functionality should mirror the above example execution description. Both
functions must make use of multiple workers simultaneously, if available,
and be able to handle both silent and explicit worker failure
and individual worker slowness. However, you don't need to handle the case
when all workers fail when there is no coding error in your worker code
(i.e. complete network failure). Also, there should only be one active
request per worker at a time, and if a worker fails, it should not be
returned to the Worker_manager
using the push_worker
function.
Both map
and reduce
share the same basic structure.
First, the workers are
initialized through a call to the appropriate Worker_manager
function. Once the workers have been initialized, the input list should
be iterated over, sending each available element to a free worker, which can
be accessed using the pop_worker
function of
Worker_manager
. A mapper is invoked using
Worker_manager.map
providing the mapper's id and the (key,
value) pair. Each mapper (and therefore invocation of
Worker_manager.map
) receives an individual (key, value) pair, and
outputs a new (key, value) list, which is simply added onto the list of all
previous map results. A reducer is invoked similarly using
Worker_manager.reduce
. These functions block until a response
is received, so it is important that they are invoked using a thread from
the included Thread_pool
module. Additionally, this requires
that these spawned threads store their results in a shared data structure,
which must be accessed in a thread-safe manner.
Once all of the input has been iterated over, it is important that any input that remains unfinished, either due to a slow or failed worker, is re-submitted to available workers until all input has been processed. Once all input has been fully processed, the results are returned.
Note: It is acceptable to use Thread.delay
with a short
sleep period (0.1 seconds or less) when looping over unfinished data to send
to available workers in order to prevent a flooding of workers with unnecessary work.
Duplicate keys: Your MapReduce framework must not make any assumptions about the uniqueness of keys passed to its mappers. In particular, it must neither rely on key uniqueness nor make any attempt to enforce it. Applications that do not rely on key uniqueness (such as word_count) must be able to run on the MapReduce framework. Applications may impose additional restrictions on their input (such as key uniqueness); it is the responsibility of the user of the MapReduce framework to adhere to these restrictions. The general MapReduce framework does not concern itself with any such restrictions.
The combine
function must be implemented according to specifications,
but doesn't need to make use of any workers. It should simply combine the provided
(key, value) pair list into a list of (key, value list) pairs such that each key in
the provided list occurs exactly once in the returned list, and each value list for a given
key in the returned list contains all the values that key was mapped to in the provided list.
worker_server/worker.ml
The code in this module is responsible for handling communication between the clients that request work and the mapper/reducers that perform the work.
The handle_request
function must be implemented
according to the mli specifications and the above description, and must be
thread-safe. This function receives a client connection as input and must retrieve
the worker_request
from that connection.
If the request is for a mapper or reducer initialization, then the code must be
built using Program.build
, which returns (Some id, "")
where
id is the worker id if the compilation was successful,
or (None, error)
if the compilation was not successful. If the
build succeeds, the worker id should be stored in the appropriate mapper or
reducer set (depending on the initialization request), and the id should be
sent back to the client using send_response
. If the build fails,
then the error message should be sent back to the client using
send_response
.
If the request is to perform a map or reduce, then the worker id must
be verified to be of the correct type by looking it up in either the mapper
or reducer set before the mapper or reducer is invoked using
Program.run
. The return value is Some v
, where v
is the output of the program, or None
if the program failed to provide
any output or generated an error.
Note that the mapper and reducer sets are shared between all request handler threads
spawned by the Worker_server
, and therefore access to them must
be thread-safe.
Note: Code in shared/util.ml is accessible to all workers by default.
We have provided a Makefile
and a build script build.bat
that you can use to build your project.
port_number
for requests.
word_count
with datafile filename.
If you would like to define additional modules, please add them to
the appropriate build.bat file or Makefile
.
You will use the simplified MapReduce that you created in part 1 to
implement three applications: inverted_index
, page_rank
, and newton
.
Each application will require a mapper apps/xxx/mapper.ml
and reducer apps/xxx/reducer.ml
,
where xxx
is the name of the application, as well as a controller
apps/xxx/xxx.ml
. We have supplied
full implementations of a simple application word_count
and a
more involved application kmeans
from a previous semester as models.
An inverted
index is a mapping from words to the documents in which they
appear. For example, if these were your documents:
Document 1:
OCaml map reduce
fold filter ocamlThe inverted index would look like this:
word | document |
---|---|
ocaml | 1 2 |
map | 1 |
reduce | 1 |
fold | 2 |
filter | 2 |
Each document must appear only once in each word's index. A document with ID 1 containing "a a a" would result in "a" -> 1 rather than "a" -> 1, 1, 1
Behavior is undefined if any two documents share the same key.
To implement this application, you should
take a dataset of documents (such as data/reuters.txt
) as input and use MapReduce to produce an inverted index.
This can be done in a way very similar to word_count
.
In particular, you can use Map_reduce.map_reduce
.
Print your final results using Util.print_reduce_results
.
Your mapper and reducer code should go in apps/inverted_index/mapper.ml and apps/inverted_index/reducer.ml, respectively, and your controller code should go in apps/inverted_index/inverted_index.ml.
PageRank is a link analysis algorithm used by Google to weight the importance of different websites on the Internet. You will be implementing a very simplified, iterative version of PageRank. To begin running simplified PageRank, we initialize each website with PageRank of 1/n, where n is the total number of websites. Each step of the iteration has two parts: For each website, we divide its PageRank by the number of links out of it, and send this amount to each website linked to. Then, for all websites, we sum up all values being sent into it, thus obtaining a new PageRank for each website. The number of iterations is supplied on the command line.
For more details on simplified PageRank, see Section 14.3 in Networks, Crowds, and Markets: Reasoning About a Highly Connected World by Cornell Professors David Easley and Jon Kleinberg.
Note: There is an unfortunate error in the example on page 408 of the networks book. On the second iteration, page A should have a PageRank of 5/16, not 3/16.
Your mapper and reducer code should go in apps/page_rank/mapper.ml and apps/page_rank/reducer.ml, respectively, and your controller code should go in apps/page_rank/page_rank.ml.
In order to simulate websites, we have defined a new type, website
.
Each line is of the format pageid@pagetitle@links. The field links is of the
form out1,out2,...,outm, where each outi is the pageid of a link out of
the page. The file data/websites.txt
contains the same example as
on pages 407 and 408 of the Networks book draft linked above.
After performing PageRank for the specified number of iterations, you should print the final PageRank values. We have provided you with a function print_page_ranks, which takes in a list of tuples of pageids and PageRanks, and prints them to the screen.
Behavior is undefined if any two pages share the same key. Behavior is also undefined if any page has zero outgoing links. However, behavior is defined if a page has zero incoming links: it naturally ends up with zero PageRank. When printing the PageRanks for each page, you must explicitly list that page with a PageRank of zero.
No page will link to another page twice, nor link to a nonexistent page; the outgoing links list for each page will contain unique valid IDs.
In this part, you will implement the application newton
which
will use Newton's Method to
compute zeroes of polynomials on complex numbers. Newton's method
is a strategy for approximating zeroes of functions which starts at an
arbitrary guess and repeatedly improves it until it (rather rapidly) reaches a
0. Recall that a complex polynomial has as many zeroes as its degree. A natural
question to ask is: Given a point in the complex plane, which zero will
Newton's method converge to when started at that point? It turns out that this
is not that easy to predict, but the results are quite interesting. If we
assign a color to each zero, then color each point in the complex plane with
the color of the zero Newton's method converges to starting at that point, the
result is a beautiful fractal.
You will be using MapReduce to compute in parallel the zero that Newton's method converges to starting from each point. To get a picture like this, we also need to keep track of the number of iterations Newton's method takes so that we can shade the positions darker if they take longer to converge.
Your application should take two command line arguments. The first is a file
containing the complex numbers we will be starting Newton's method from. The
file will have one pair of real numbers which specify a complex number on each
line. The second is a string of floating point numbers like "3.0, 4.0,
-1.0, 0.0"
. This specifies the polynomial we will use. We provide a
function polynomial_of_string
that takes input of this form and
evaluates to something of type polynomial
which is just a list of
floats. This list corresponds to a polynomial that has degree equal to the
length of the list minus one. The coefficient of the highest order term is the first
entry, the coefficient of the second highest order term is the second entry and
so on. If any term has coefficient 0, a zero must appear in the list. So if you
input "3.0, 4.0, -1.0, 0.0"
, this will be mapped to the polynomial
3x^3 + 4x^2 - x.
In the map phase, you will take a point and will return the pair of the
zero Newton's method converges to as the key and a tuple of the starting
complex number and the number of iterations Newton's method takes as the value.
Since these are just approximations, you should cut off both components of the
zero at 1 decimal point (e.g. 1.55 becomes 1.5), or else we will have far more
unique zeroes than actually exist. We will not test your code with polynomials
that have zeroes so close together that this approximation does not work.
Unfortunately, Newton's method does not necessarily converge from any point. It
can fail if the derivative it uses to compute the next approximation evaluates
to zero, or it can simply fail to converge. If Newton's method started at some
point does not converge (we say that we have failed to converge if we have gone
through 500 iterations of Newton's method without reaching a zero) you must
store this as the key instead of the position of the zero. (Hint: the option
type is useful here). There are some helper functions in Util that should be
useful in implementing the mapper. Among these, we provide a type
complex
which is a record
along with all of the functions over complex numbers that are necessary to find
the approximation of the zero.
As usual, the combine phase will simply group together all the (starting point, number of iterations) pairs that share a zero as a key. The reduce phase should normalize the number of iterations to the range (0,1) so that it is convenient for drawing the fractal. One simple strategy for doing this is to divide the number of iterations associated with each point by some number greater than the maximum number of iterations for any point that causes Newton's method to converge to that zero. All points that do not result in convergence to any zero should be normalized to precisely 1.
We provide to you two scripts for drawing the fractal that you have computed:
Your mapper and reducer code should go in apps/newton/mapper.ml and apps/newton/reducer.ml, respectively, and your controller code should go in apps/newton/newton.ml. This app requires a set of points as an input. An input file has lines of the form xi, yi. We provide you with the function Util.load_coordinates to load such a file into a list of points in the complex plane. Some sample files of this format are c.txt, c2.txt, cold.txt. To generate more points, we have provided you with a script data/make_points.py. You should print your reduce results using the functions we have given you in newton.ml.
Note that for the above applications, your MapReduce code will probably run a lot slower than a non-MapReduce implementation of the same algorithm. This slowdown is due to the fact that there is a lot of overhead and the simplified MapReduce framework is not very well optimized. Performance gains are only realized when doing this on a massive scale.
Simply zip up and submit your entire ps5 folder.
You are required to use a source control system like Subversion or Git. Submit the log file that describes your activity. We will provided you with an SVN repository, hosted by CSUG.
For information on how to get started with SVN there, read Using Subversion in the CSUGLab.
Note: Your repository name is cs3110_netid1_netid2
. The netIDs of
groups are in alphabetical order. For example:
cs3110_gez3_rz13
. This repository name is what you put in place
of project1
in the directions in the provided link.
If you use Windows, and are unfamiliar with the command line or Cygwin, there is a GUI based SVN client called Tortoise SVN that provides convenient context menu access to your repo.
For Debian-based Linux distros such as Ubuntu, a GUI-based solution to explore would be Rapid SVN. To install:
apt-get install rapidsvn
Mac users looking into a front-end can try SC Plugin, which claims to provide similar functionality to Tortoise. Rapid SVN might work as well.
There is also a plug-in for Eclipse called Subclipse that integrates everything for you nicely.
Note that all of these options are simply graphically based alternatives to the extremely powerful terminal commands, and are by no means necessary to successfully utilize version control.
We will be holding 15-minute design review meetings. Your group is expected to meet with one of the TAs or the instructor during their office hours, or with consultants during consulting hours. A sign-up schedule is available on CMS. You should be able to explain your design in about 10 minutes, leaving 5 minutes for questions. It's a good idea to practice your presentation ahead of time so you use your time effectively.
Your design review should focus on your approach to Part 1, however time permitting you may spend a few minutes at the end on Part 2.
In your design review, plan to talk about at least:
