Support LLVM GlobalISel for RISC-V Vector Extension on Partial ALU Instructions

by Jiahan Xie, Michael Maitland

Introduction

The open RISC-V instruction set architecture (ISA) has an interesting extension, the RISC-V “V” Vector Extension. The unique part of RISC-V Vector Extension is that its vector instructions can deal with flexible vector lengths, VL, which makes programming in RISC-V Vector Extension agnostic to the vector register sizes. This feature really distinguishes the RISC-V Vector Extension from the traditional SIMD extensions, such as x86 SSE (with a fixed size 128-bit vector length)/AVX (256-bit), and Arm NEON (128-bit). Traditional SIMD extensions with fixed vector lengths face challenges when dealing with the changing data sizes. They must maintain compatibility and support all existing fixed-size vector lengths in their instruction set architectures. This may lead to inefficiencies, especially in loop operations where the data size/loop stride may not align perfectly with the fixed vector size, necessitating additional scalar processing for the remaining elements. And the most suitable size for the number of elements to be processed in the vector loop is hard to decide ahead of time. In contrast, the RISC-V Vector Extension eliminate this concern with its vector length agnostic principle. Particularly in loop scenarios, the RISC-V’s ability to adaptively handle varying data sizes stands out. For instance, in a simple loop adding two arrays, the RISC-V program can dynamically adjust the vector length for each iteration by dynamically setting the vector length. This means it can process as many elements as possible in each pass, depending on the hardware capabilities and the remaining data. This adaptive approach really simplifies the code by eliminating the need for separate scalar loops for the leftover elements.

In this project, our goal was to support LLVM Global Instruction Selection (GlobalISel), a framework that operates on whole functions for instruction selection, for the RISC-V Vector Extension on some ALU operations, such as vadd, vsub, vand, vor, and vxor. Apart from adding support for RISC-V vector types and operations for GlobalISel by going down GlobalISel’s pipeline, it’s a challenge to bridge the LLVM world (concepts like scalable vector) and the RISC-V world (concepts like vector length and vector register grouping factor) together. And we will showcase how we address the challenge in the following sections.

A Primer on the RISC-V Vector Extension

There are a lot of instructions and cool features in the RISC-V “V” Vector Extension Spec, I will only pick the most relevant and important parts to explain.

The most important parameters are undoubtly SEW, ELEN, VLEN, VL, and LMUL; and one of the most interesting and powerful instructions is vset{i}vl{i}.

Let’s begin with the crucial parameters:

After introducing these basic and the most important parameters, there are still two paramters we will be dealing with, AVL and VLMAX:

The visualization of vector registers is shown below:

One of the most interesting instructions is vset{i}vl{i}, which configures the vector length. The vset{i}vl{i} instructions set the vtype and VL based on arguments, and write the new value of VL into rd. Take vsetvli as an example, the spec of vsetvli is:

vsetvli rd, rs1, vtypei   # rd = new vl, rs1 = AVL, vtypei = new vtype setting

Say we have a vsetvli instruction:

vsetvli	t0, a0, e64, m2, ta, ma

The SEW is therefore 64-bit (e64); the vector length multiplier is 2 (m2); the AVL is held in a0; the new VL = min(AVL, VLMAX) is stored in t0; the tail and mask policy is tail agnostic (ta) and mask agnostic (ma), which is not our concern in this blog.

A Primer on LLVM Global Instruction Selection

LLVM Global Instruction Selection (GlobalISel) is a framework that provides a set of reusable passes and utilities for instruction selection — translation from LLVM IR to target-specific Machine IR (MIR). It is “global” in the sense that it operates on the whole function rather than a single basic block.

GlobalISel is intended to be a replacement for SelectionDAG and FastISel, to solve performance, granularity, and modularity problems. GlobalISel does not need to introduce a new dedicated IR as in SelectionDAG so GlobalISel can provide faster code generation; GlobalISel operates on a function, whereas SelectionDAG only considers a basic block, losing some global optimization opportunities; in addition, GlobalISel enables more code reuse for instruction selection for different targets.

The pipeline of GlobalISel composes of four major passes:

  1. IRTranslate: Converts LLVM IR into Generic MachineIR (gMIR), which has the same data strucures as MachineIR but is less constrained. The constraints will be incrementally enforced along with the pipeline, transforming gMIR to MIR in the end.
  2. Legalize: This pass replaces unsupported operations with supported ones. So there will be no illegal instructions after this step.
  3. Register Bank Select: This pass assigns the corresponding Register Banks to the generic virtual registers in the gMIR. In essence, Register Bank is a framework for grouping and managing different sets of registers in a target architecture.
  4. Instruction Select: This is the final pass, it selects target MIR instructions based on the gMIR instructions. As mentioned above, the gMIR has been constrained enough that it becomes MIR at this point.

A visualization of the pipeline is shown below:

Please note that Combiner, which is an optional optimization in GlobalISel that replaces patterns of instructions with a better (faster or smaller code size) alternative, is not in the scope of this blog.

The Core Pipeline and My Implementation

Let’s start with a minimum code generation example that we want to support in LLVM GlobalISel:

define <vscale x 1 x i8> @vadd_vv_nxv1i8(<vscale x 1 x i8> %va, <vscale x 1 i8> %b) {
  %vc = add <vscale 1 x i8> %va, %vb
  ret <vscale x 1 x i8> %vc
}

Here, we define a vector-vector add function that takes in two vector arguments, and returns the sum. For the background knowledge of LLVM vector types, it has both fix-length vectors and scalable vectors. We will be focusing on scalable vectors not only because it’s more complex and flexible, it also fits into our abovementioned discussion regarding flexible-widths RISC-V vector registers. The form of scalable vectors in LLVM is as follows:

<vscale x M x primitive data type>

where M is the minimum number of elements in the vector; a primitive data type; and vscale is a positive constant multiple of the specified number of vector elements, and vscale is unknown at compile time. For example, <vscale x 4 x i32> represents a scalable vector, which can be any positive multiple (for example, 1, 4, 16, etc.) of 4 32-bit integer values. Although it’s unknown at compile time, it remains constant during runtime (for example, the user passes vscale as the program input).

Since there are four passes in the LLVM GlobalISel core pipeline, my design and implmentation are also based on these four passes.

IRTranslator

IRTranslator is the first pass of GlobalISel pipeline. The goal of this pass is to translate LLVM IR into gMIR. And the essential thing that is happening in this pass is call lowering according to the ABI rules of the target, which is RISC-V in our case. The proposal of vector calling convention can be found here.

If we recall our example, what we want to get out of the first pass is something like:

%vc:_(<vscale x 1 x i8>) = G_ADD %va:_(<vscale x 1 x i8>), %vb:_(<vscale x 1 x i8>)

To achieve this, we need to first support parsing scalable vectors and to implement three main parts in call lowering, namely lowerReturn, lowerFormalArguments, and lowerCall. The functionalities of these three main parts are as what their names have suggested:

  1. lowerReturn enables functions to return scalable vector types. To be specific, scalable vector types in the input LLVM IR programs can be lowered into physical vector registers MIR based on the RISC-V vector calling conventions for return instructions. To implement this, we just write a function that translate to a return MIR if the return value is a scalable vector. It used to fall back to SelectionDAG before we implement this, now we can directly enable it in GlobalISel. This patch implements this functionality.
  2. lowerFormalArguments supports passing scalable vectors as arguments. We do it by implementing a function that takes in type information and returns true/false based on the type and other relevant information, such as if the target hardware supports vector instructions, and so forth. The existing argument-lowering function can take this as a helper function and enables passing scalable vectors as function arguments. This patch supports lowering formal arguments.
  3. lowerCall is used to lower the given call instruction according to the ABI. Note that lowerCall is not yet implemented for vectors on RISCV since it was not a blocker to do CodeGen for vector add.

Legalizer

After the IRTranslator translates the input program written in LLVM IR into: %vc:_(<vscale x 1 x i8>) = G_ADD %va:_(<vscale x 1 x i8>), %vb:_(<vscale x 1 x i8>), we want to legalize all the types and operations.

Before explaining our work, let’s define what does “legal” mean in LLVM GlobalISel. An instruction is legal if the target (RISC-V in our case) will later be able to select it to a target-specific MIR instruction.

Prior to our support, the G_ADD operation is legal for scalar types. Scalable vectors as Low Level Types are theoretically legal in GlobalISel, but it has not been legalized, so we focused on legalizing the LLTs. Just as a note, Low Level Type (LLT) is intended to replace the usage of Extended Vector Type (EVT) in SelectionDAG. LLTs are specified in terms of whether they are scalar or vector, and their widths; but they don’t differentiate between integer and floating values. For example, LLT s16 is simply defined as LLT::scalar(16). For scalable vector types, if we want to define nx4s32 (<vscale x 4 x s32>), it’s nothing but LLT::scalable_vector(4, s32).

Since we just brought up LLT, I’d like to introduce how to concretely associate the VLEN, LMUL things we discussed before with LLVM scalable vector types. Please note that as the date of this blog post, the LLVM community only has comprehensive support when vscale == VLEN/64, where 64 is the magic constant for the minimum vector register length (assumed by LLVM not RISC-V), that is to say, we currently require that VLEN >= 64. We only have partial support for VLEN=32 using intrinsics when vscale is not used and there is no spill/reload of vectors. Supporting VLEN=32 would require twice as many instruction selection patterns in RISCVGenDAGISel.inc which is already a very large table so the community hasn’t done it. With that being said, I can present the chart of how RISC-V vector types are mapped to LLVM types for integers:

LMUL
/           1/8    1/4     1/2     1       2       4        8
SEW
i64         N/A    N/A     N/A     nxv1i64 nxv2i64 nxv4i64  nxv8i64
i32         N/A    N/A     nxv1i32 nxv2i32 nxv4i32 nxv8i32  nxv16i32
i16         N/A    nxv1i16 nxv2i16 nxv4i16 nxv8i16 nxv16i16 nxv32i16
i8          nxv1i8 nxv2i8  nxv4i8  nxv8i8  nxv16i8 nxv32i8  nxv64i8

The complete chart can be found in this RISCV/RISCVRegisterInfo.td file. And note that MF stands for fractional LMUL and Ms are integer LMULs.

Some values are N/A because currently the LLVM community assumes the RISC-V vectors to have VLEN=64. Take the combination (1/8, i16) as an example. If we were to write it in terms of LLVM scalable vectors, it would be nx1/2i16 ((64 x 1/8) / 16 = 1/2), which is illegal. Now consider a legal (LMUL, SEW) combination: (i32, 4). Since VLEN = 64 and SEW = 32, there are 64/32 = 2 elements that can fit in a single vector element. And since the grouping factor is 4, there are 2*4 = 8 multiples of elements, hence nxv8i32 == <vscale x 8 x i32>.

The legal scalable vector types in the chart should all be legalized in the legalize pass. To implement this, we use the getActionDefinitionsBuilder function in the LegalizerInfo class. In addition, we utilize the LegalityQuery structure to query and filter the input LLTs.

It is noteworthy that some target hardwares only support ELEN = 32; on the other hand, nxv1i64, nxv2i64, nxv4i64, and nxv8i64 require the maximum size in bits of a vector element is 64. For example, in Zve, Vector Extensions for Embedded Processors, Zvex32 does not provide support for SEW = 64. To this end, we need to have extra separate files when the target hardwares are different, which will be discussed further in the evaluation part.

This patch implements the legalize pass.

Register Bank Select

RegisterBankSelector essentially binds generic virtual registers to register banks. A virtual register, in LLVM, is a temporary, abstract placeholder representing a storage location that’s not yet mapped to a specific physical hardware register. And generic virtual registers means they are virtual registers but yet have not assigned with Register Class constraints. Basically, Register Banks are sets of register classes defined by a target architecture, used to optimize register allocation by clustering related data into specific register files, thus minimizing data copying and accommodating operation-specific constraints.

Therefore, the goal in this pass is to take the input as the results of the legalizer, %vc:_(<vscale x 1 x i8>) = G_ADD %va:_(<vscale x 1 x i8>), %vb:_(<vscale x 1 x i8>), and assign register banks for the results and the operands. At the end of this pass, we expect to see %vc:vrb(<vscale x 1 x i8>) = G_ADD %va:vrb(<vscale x 1 x i8>), %vb:vrb(<vscale x 1 x i8>), where vrb stands for vector register banks. Just to provide complete context and background information, there are three types of register banks in RISC-V:

At the end of the day, to assign the instructions with proper register banks, we will utilize the function getInstructionMapping and call it on the opcodes we are working on. To make sure we are mapping our instructions to their correct register banks, we still need more helper functions to achieve that.

Particularly, we need a function to map operands values to register banks by using the ValueMapping structure because that is the function that bridges the LLVM world and the RISC-V world. And we will create the mapping based on the size of the incoming operands. The rule here is we have 4 different sizes in the mapping for the 4 different integer LMUL register size cases. We pick based on the known minimum size of the register type, 64, 128, 256, and 512. We map any size less than 64 to 64 as well. And the reason being is MF8, MF4, and MF2 have similar behaviors as M1; but M2, M4, and M8 do not. Consider we have two instructions that use vsetvli to set LMUL to 1/2 (MF2) and 1 (M1) respectively. Assume we want to read a vector register in the first instruction. We can only read/extract the first half of that vector register, say v1, out of it since we have fractional LMUL MF2. In that sense, regardless of using MF2 or M1, we are essentially using the whole registers so they all take one cycle to process even in the case of fractional LMULs. However, if we set LMUL to 2, if we were reading v1, we end up reading a group of 2 registers: {v1, v2}. And this behavior is fundamentally different from the former case.

Instruction Select

Now that we have assigned the correct register banks, we are ready to implement the last pass, InstructionSelect, to select the target MIR using the gMIR!

Let’s recall the result produced by the Register Bank Select pass: %vc:vrb(<vscale x 1 x i8>) = G_ADD %va:vrb(<vscale x 1 x i8>), %vb:vrb(<vscale x 1 x i8>). We’d like to use the corresponding MIR of RISC-V vector add instruction to replace the generic add G_ADD instruction. Please note that I said “the corresponding MIR” because we will not be generating the actual RISC-V vadd or vsetvli in the current pass. It’s because the process of instruction selection involves transforming code into target-specific MIR/machine instructions. Later down the pipeline, the RISCVInsertVSETVLI function, for example, will execute. Additionally, the RISCVAsmPrinter will translate MIR into MCInst at later stage, representing the final assembly language form. With that being said, what we actually want to get out of instruction selection pass is in this form: %vc:vr = PseudoVADD_VV_MF8 %va, %vb, -1, 3 /* e8 */, 3 /* ta, ma */, where PseudoVADD_VV_MF8 is a RISCV specific vector instruction pseudo for vector-vector add with LMUL = 1/8, the position where -1 stands is for the VL operand and -1 means VLMAX, the first 3 stands for SEW as log2(8) = 3, and the second 3 is the encoding for the policy tail agnostic and mask agnostic. RISC-V vector instruction pseudos in LLVM are essentially used for efficiently handling the complex, vtype-dependent behavior of vector instructions, such as in register allocation.

Implementation-wise, the select function is invoked, which in turns call the corresponding RISC-V selectImpl function. To achieve this final phase, there are essentially four steps to take. First is to identify the vectorized opcode/gMIR; then we create the lowered version of that gMIR using the vector instruction pseudos; and we need to erase the old instruction once the lowered version has been picked; finally we constrain the type of the virtual register so that register allocation has enough information to convert this virtual register into a physical register. For this final phase in GlobalISel, if there exist LLVM TableGen patterns that can map to RISC-V opcode by going through SelectionDAG, we can just use it out-of-the-box; otherwise, we need to implement extra logics to customize the selection pass outlined above. Luckily, TableGen does have this pattern and we only need to implement some helper functions to mesh everything together.

This patch implements both Register Bank Select and Instruction Select passes.

Challenges and Triumphs

Learning the whole LLVM and its GlobalISel infrastructure were the hardest parts to support GlobalISel for the RISC-V Vector Extension, especially for someone who was new to the LLVM world. It was also hard to understand the vector length agnostic features/instructions in the RISC-V vector extension in particular.

LLVM is a huge project and it was hard to navigate at the beginning. They have the TableGen file, all the CodeGen GlobalISel source code, and the target-specific (RISC-V in our case) implementations. They also have all the regression tests infrastructure that I had to learn at the beginning. Besides, the GlobalISel infrastructure is also rather new and under active development as well. And since we are one of the earliest people start supporting RISC-V vector extension in LLVM GlobalISel, there had been some extensive research and discussion going on. And we didn’t have that many existing work to refer to, so we had to start pretty much from scratch. My initial strategy was to look at AArch64 GlobalISel for their vectors because AArch64 is one of the pioneers in GlobalISel and their work is pretty mature.

Learning the RISC-V vector extension was also a headache at the beginning because I had to figure out the difference between RISC-V vector extension with standard SIMD vector instructions. Learning the semantic meaning of vsetvli, differentiating the concepts of ELEN, VLEN, and how SEW, LMUL, VLMAX come into play was also confusing.

Nevertheless, this project turns out to be a success and we have become one of the first developers to support GlobalISel for the RISC-V vector extension, as well as the first developers to support scalable vectors in GlobalISel for any target.

We evaluate our work using LLVM Regression tests. The regression tests are driven by lit, LLVM Integrated Tester. Each pass of GlobalISel is testable (that’s also one of the advantages of GlobalISel over SelectionDAG). The root test directory for RISC-V GlobalISel is located in llvm/test/CodeGen/RISCV/GlobalISel, in which it has irtranslator, legalizer, regbankselect, and instruction-select directories to test each pass. We first make sure that our implementation still pass all the existing regression tests. Then, we generate more regression test assertions using Python scripts update_llc_test_checks.py and update_mir_test_checks.py located under llvm/utils/. We test for every pass, for all the opcodes we intend to support, and for all the scalable vector LLT types available in the RISC-V vector extension. And as a result, we achieve 100% correctness. Although didn’t “optimizie” anything explicitly, when I compare our GlobalISel outputs with the outputs from SelectionDAG, which is typically used as the ground truth for now, and they turn out to be the same, meaning we have an “optimal” code generation implementation.

There are numerous benefits of this work. As we have mentioned before, GlobalISel is intended to replace SelectionDAG and FastISel to solve some major problems. Since GlobalISel operates on the whole function, supporting GlobalISel for RISC-V vector extension can allow for more efficient code generation globally tailored to the unique features of this extension, such as variable vector lengths and diverse operation types. GlobalISel also eliminates the use of dedicated IRs as in SelectionDAG, it streamlines the compilation process by providing this more unified and efficient approach to instruction selection, which can be particularly beneficial for the complex operations involved in vector processing. Last but not least, as GlobalISel is built in a way that enables code reuses, our work also provides a foundation of the framework that can be extended and customized for future work, enabling long term reusability and adaptability.

Future Work

It’s absolutely been a fun and rewarding experience, and I plan to keep supporting more opcodes, such as vector load/store, in LLVM GlobalISel for the RISC-V vector extension. When more opcodes are supported and we are ready to write actual interesting high-level language programs, I will also try to write some, for example, C programs, and run them on simulators like Spike.
