Exhibit 4 Textures and Transparency

What are we doing?

• Some image file formats contain the alpha channel, which specifies the transparency of the pixels.
  • PNG and GIF file formats has it, but JPG does not.
• Here, we have three images:

  Sky	Mountain	Ground

• In WebGL, alpha channel is generally used in tandem with blending.
  • Howerver, you can write your shader to do whatever you want with it, like what we did in Exhibit #3.
• To simulate the transparency that is commonly understood (i.e., alpha indicates how much the image allows what behind it to be seen), you need to do three things:
  • Enable blending and use gl.SRC_ALPHA and gl.ONE_MINUS_SRC_ALPHA as your blend functions.
  • Draw your images from BACK TO FRONT. This is very important.
  • In the fragment shader, just fetch and output the texture value. No special processing is required.
• Btw, we took the images from OpenGameArt. They were created by bevouliin.com, and the images are in the public domain. We're very thankful of this generous artist.
  • If you want to look for art assets for your final project, OpenGameArt is a good place to start.
