Website http://msnbc.msn.com/id/10877076/ says that, "the rhinoceros population has declined by 90 percent since 1970, with five species remaining in the world today, all of which are endangered. The white and black rhinos are the only species left in Africa... . " Lately, Kenya (with less than 500 rhinos left!) relocated 33 rhinos to Meru National Park, where they hope to protect them from poachers. Poachers kill the rhinos for their horns.
Rhinos are not the only endangered species. Web page http://www.redlist.org/ will tell you that the number of endangered vertebrates (mammals, birds, reptiles, amphibians, and fishes) grew from 3,314 in 1996/98 to 5,188 in 2004. Of the 22,733 evaluated species 23% were endangered. See http://www.worldwildlife.org/endangered for more info on endangered species.
When an animal population is small, the animals can be monitored. Sometimes they will be captured and tagged. Some tags emit a signal, so that one can track the animal. Even in populated places, animals are tagged. Here in Ithaca, one can see deer with tags on their ears wandering in the fields. Gries sees them often in his back yard near Community Corners. Some of the rhino pictures were downloaded from www.birdingafrica.net.
This assignment illustrates how Java's classes and objects can be used to maintain data about a collection of things —like individual rhinos in a park. Read the WHOLE handout before you begin to do the assignment. You may do this assignment with one other person. If you are going to work together, then, as soon as possible, get on the CMS for the course and do what is required to form a group.
For this assignment, you are required to design and implement two classes. Class Rhino
is used by to keep track of rhinos. It has lots of fields and methods, but each method is simple.
If you do one thing at a time, and start early, you should
have little trouble with this assignment. Class RhinoTester
, a JUnit class, is used to test class Rhino
. Do not think too much about
this class when first reading this handout. Wait until we tell you how to write such classes before starting.
If you don't know where to start, if you don't understand testing, if you are lost, SEE SOMEONE IMMEDIATELY. Gries, a TA, a consultant. Do not wait. Almost 100 of you have never programmed before, and it is reasonable to expect that you may not fully graps everything. But a little one-on-one help can do wonders.
An instance of class Rhino
represents a single rhino. It has several
fields that one might use to describe a rhino, as well as methods that operate
on these fields. Here are the fields, all of which should be private (you can choose the names of these fields).
String
) — true
for female and false
for male)int
)int
)int
)Rhino
object)Rhino
object)int
)int
)Here are some details about these fields:
Rhino
objects that correspond to this rhino's parents. They are null
if not known.RHINO
OBJECT IS CREATED, THIS FIELD SHOULD BE INCREASED BY 1. Accompanying the declarations of these fields should be comments that describe what each field means —what it contains. For example, on the declaration of
field tag
, one should put that the field is –1 if the rhino is untagged and the tag number itself (≥ 0) if the rhino is tagged. The collection of these fields is called the "class invariant".
Whenever you write a method (see below), look through the class invariant and convince yourself that the class invariant is correct when the method ends, for all objects of class Rhino
. For example, if the method does something to the mother field of the object, are all the mother-object fields correct?
Class Rhino
has the following methods. Pay close
attention to the parameters and return values of each method. The descriptions,
while informal, are complete.
Constructor | Description |
---|---|
Rhino(String name, boolean female, int month, int year) |
Constructor: a new |
Rhino(String name, boolean gender, Rhino father, Rhino mother, int month, int year) |
Constructor: a new |
Method | Description |
---|---|
getName() |
= the name of this rhino (a String ) |
getGender() |
= the gender of this rhino (a boolean ). |
getMOB() |
= the month in which this rhino was born, in the range 1..12 (an
int ). |
getYOB() |
= the year in which this rhino was born (an
int ). |
getFather() |
= (the name of the object representing) the father of this rhino
(a Rhino ). |
getMother() |
= (the name of the object representing) the mother of this rhino
(a Rhino ). |
getNumberChildren() |
= the number of children of this rhino (an int ). |
getTag() |
= this rhino's tag (–1 if none) (an int ) |
getPopulation() |
Static method. = the number
of Rhino objects created thus far (an int ).
|
toString() |
= a String representation of this Rhino . It has to be in a precise format discussed below. |
Method | Description |
---|---|
setName(String n) |
Set the name of this rhino to n . |
setGender(boolean g) |
Set the gender of the rhino to g . |
setMOB(int i) |
Set the month of birth for this rhino to i . |
setYOB(int i) |
Set the year of birth for this rhino to i . |
setTag(int t) |
Set whether this rhino's tag to t. Precondition: t ≥ 0 and the tag is currently –1. |
setFather(Rhino r) |
Set this rhino's father to r (and increment r's number of children).Precondition: This rhino's father is null , r is not null , and r is male. |
setMother(Rhino r) |
Set this rhino's mother to r (and increment r's number of children).Precondition: This rhino's mother is null , r is not null , and r is female. |
isOlder(Rhino r) |
= "this rhino is older than r " (a |
areSameAge(Rhino r1, Rhino r2) |
Static function. = " |
isBrother(Rhino r) |
= " |
isSister(Rhino r) |
= " |
areSiblings(Rhino r1, Rhino r2) |
Static method. = " |
isMotherOf(Rhino r) |
= "this rhino is |
isFatherOf(Rhino r) |
= "this rhino is |
isParentOf(Rhino r) |
= "this rhino is |
areTwins(Rhino r1, Rhino r2) |
Static method. = " |
|
|
Make sure that the names of your methods match those listed above exactly, including capitalization. The number of parameters and their order must also match. The best way to ensure this is to copy and paste. Our testing will expect those method name and parameters, so any mismatch will fail during our testing. Parameter names will not be tested —you can change the parameter names if you want.
Each method must be preceded by an appropriate specification, as a Javadoc comment. The best way to ensure this is to copy and paste. After you have pasted, be sure to do any necessary editing. For example, the spec does not have to say that a function is static, because that is known from the header of the method. And the spec of a function does not have to say that the function yields a boolean or int or anything else, because that is known from the header of the method.
A precondition should not be tested by the method; it is the responsibility
of the caller to ensure that the precondition is met. As an example, in method isMotherOf
, the method body should not test whether fm
is
null
. However, in function areSiblings
, the tests for fm1
and fm2
not null
MUST be made.
The number of children of a newly created rhino is 0. Whenever a rhino R is made the mother or father of another rhino, R's number of children should increase by 1.
It is possible for person R1 to be R2's mother, and visa versa, at the same time. We do not check for such strange occurrences.
Function toString
Here is an example of output from function toString:
"Male rhino Fatso. Tag 34. Born 6/2005. Has 2 children. Father Weighty. Mother unknown."
Here are some points about this output.
null
, use "unknown" for its name; otherwise, use the name that appears in the mother or father.Your method bodies should have no if statements. Your method bodies should contain only assignments and return statements. Points will be deducted if if statements are used. Further, conditional expressions may be used only in function toString.
How do you know whether class Rhino
that you are designing
is correct? The only way to be sure is to test it, to see if it does
what it is supposed to do. It is not enough simply to try out your class Rhino
in the interactions pane. Every time you write a method for your class
Rhino
, you should also write a couple of tests for it.
Further, you should run your collection of tests frequently to make sure that everything works
correctly.
Class RhinoTester
will contain your JUnit test suite;
it will perform these testing tasks for you. Make sure that your test suite
adheres to the following principles:
Rhino
, your test suite
should have at least one test case that tests that method.
null
, there should be a test case that has that argument as null
. If a test changes static variables, they will retain their values in later tests. Also, the tests are not necessarily run in the order in which you list them in your test suite. So when testing static variables, record their initial value at the beginning of the test and test that the change in the value is what you expect.
Rhino
using DrJava. In it, declare the fields in class Rhino
, compiling
often as you proceed. Write comments that specify what these fields mean. Rhino
.RhinoTester
that tests whether the first constructor and all the getter methods work.RhinoTester
to test it thoroughly.Rhino
to test them, and test them. We suggest writing and testing one method at a time —write a method, put tests for it in class RhinoTester
, and test it thoroughly; then move on to the next. RhinoTester
to test the comparison methods. Then work on one of the comparison methods at a time: put in its header and specification (as a comment), write the method body, add test cases to the method in RhinoTester, and test and debug until the method works properly.At each step, make sure all methods are correct before proceeding to the next step. When adding a new method, cut and paste the comment and the header from the assignment handout and then edit the comment.
if
statements
when completing this assignment. For boolean expressions, the operators &&
(AND), ||
(OR), and ! (NOT) are sufficient to implement all
the methods shown above. You will lose points for using if
statements.
Rhino
methods can be
implemented easily by using other Rhino
methods that
you have already created. Look for these cases. Take advantage of them
as much as possible.
substring
, toUpperCase
, and toLowerCase
in class String
may be useful.
String
literal is enclosed
in double quotation marks and a char
literal is enclosed in
single quotation marks.
.equals
to compare objects
(including String objects) for equality and ==
to compare primitive values for equality.
null
.
So comparisons between primitive types and null
are not legal.
File
->�New JUnit Test Case
, and then replace the testX
method
with many methods that test your Rhino
functionality.
Submit only files that end with the .java
. Be careful about this, because in the same place as your .java
files you may also have files that end with .class
or .java~
. but otherwise have the same name.
